Tower-to-Rack and Rack-to-Tower Conversion Guide
17
Figure 1-8. Installing Shoulder Nuts
Removing the Rack Doors
You must remove the doors from the rack cabinet to provide access to the interior of the rack and to
prevent damage to the doors while installing the system in the rack cabinet.
See the documentation provided with the rack for instructions on removing rack doors.
Installing the System in a Rack
If you are installing the system in a rack cabinet, see the procedures contained in the system Rack
Installation Guide.
Installing the Cable-Management Arm
See the procedures contained in the system Rack Installation Guide.
Routing Cables
See the procedures contained in the system Rack Installation Guide.
Installing the Rack Bezel
To install the bezel, hook the right end of the bezel onto the chassis, then fit the free end of the
bezel onto the system. Secure the bezel with the keylock. See Figure 1-9.
shoulder
nuts (6)
