62 Display
6 Replace the display assembly ("Replacing the Display Assembly" on
page 55).
Display-Panel Brackets
Removing the Display-Panel Brackets
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the display assembly (see "Removing the Display Assembly" on
page 53).
3 Remove the display bezel (see "Removing the Display Bezel" on page 56).
4 Remove the display panel (see "Removing the Display Panel" on page 58).
5 Remove the four screws (two on each side) that secure the display-panel
brackets to the display panel.
6 Remove the display-panel brackets off the display panel.
1 display panel brackets (2) 2 screws (4)
1
2
