Display 53
11
Display
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell™ is not covered
by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery" on page 13) before working inside the computer.
Display Assembly
Removing the Display Assembly
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the battery (see "Removing the Battery" on page 13).
3 Remove the memory module(s) (see "Removing the Memory Module(s)"
on page 15).
4 Remove the Mini-Card(s) (see "Removing the Mini-Card(s)" on page 21).
5 Remove the hard drive (see "Removing the Hard Drive" on page 27).
6 Follow the instructions from step 4 to step 6 in "Removing the Optical
Drive" on page 31.
7 Remove the palm-rest assembly (see "Removing the Palm-Rest Assembly"
on page 35).
8 Remove the keyboard (see "Removing the Keyboard" on page 41).
9 Remove the two screws that secure the display assembly to the base cover.
