44 Keyboard
2 Slide the keyboard backlight cable into the system-board connector and
press the connector tabs into the connector to secure the cable.
3 Route the keyboard cable through the routing guide on the top cover.
4 Slide the keyboard cable into the system-board connector and press the
connector tabs into the connector to secure the cable.
5 Slide the tabs on the keyboard into the slots on the top cover and lower the
keyboard into place.
6 Replace the two screws that secure the keyboard to the top cover.
7 Replace the palm-rest assembly (see "Replacing the Palm-Rest Assembly"
on page 38).
8 Follow the instructions from step 5 to step 6 in "Replacing the Optical
Drive" on page 33.
9 Replace the hard drive (see "Replacing the Hard Drive" on page 28).
10 Replace the memory module(s) (see "Replacing the Memory Module(s)"
on page 17).
11 Replace the battery (see "Replacing the Battery" on page 14).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
