Dell Latitude L400 - Manual (Page 74)

Parallel unidirectional, bidirectional, or ECP connector
IDE IDE connector for external media bay
Video SVGA connector
PS/2 mini-DIN connector
Audio microphone-in jack;
headphones/speakers jack
USB USB-compliant connector
Docking connector for the Dell Latitude L400 Advanced Port Replicator (APR)
Modem RJ-11 connector
NIC RJ-45 connector
Audio
Audio type Sound Blaster (software emulation-capable)
Audio controller Crystal CS4281 + CS4297A (AC97 CODEC)
Stereo conversion 20-bit digital-to-analog and 18-bit analog-to-digital
Interfaces:
Internal PCI bus/AC97
External microphone-in minijack;
headphones/speakers-out minijack
Speaker 4-ohm speaker
Internal speaker amplifier 1.75 W
Controls volume can be controlled through key combinations, application program menus, or the
Speaker window in the Dell Control Center (Windows 95 only)
Video
Data bus AGP
Video controller ATI Mobility M
Video memory 4 MB
Display
Type 12.1" XGA TFT
Dimensions (active area):
Height 184.3 mm (7.25 inches)
Width 245.76 mm (9.67 inches)
Diagonal 307.3 mm (12.1 inches)
Maximum resolution/colors 1024 x 768; 262,144 colors
Response time (typical) 10 – 30 ms
Viewing angles:
Horizontal ± 45°
Vertical +15°/–30°
Dot pitch 0.24 mm
Power consumption:
Panel (typical) 891 mW
