Introduction: Dell™ Latitude™ L400 User's Guide
Overview
Dell Latitude L400 portable computers are expandable multimedia systems designed around an Intel ® Mobile Pentium® III microprocessor that
includes Peripheral Component Interconnect (PCI) and Intel SpeedStep™ technologies. This section describes the major hardware and software
features of your computer.
Figure 1 , Figure 2 , and Figure 3 show the front/right, back/left, and bottom views of the computer.
Figure 1. Front/Right View of the Computer
NOTICE: To avoid overheating the computer, do not place the external media bay close to the air inlet or fan intake/exhaust vents
(see Figure 2).
NOTICE: Do not confuse the modem and NIC connectors on your computer. Do not plug a telephone line into the NIC connector
(see Figure 2).
Figure 2. Back/Left View of the Computer
Overview Available Options
Features Getting Help
1 Power button
2 Display latch
3 Drive access indicator
4 Pad Lock (Num Lock) indicator
5 Caps Lock indicator
6 Scroll Lock indicator
7 Integrated microphone
8 PC Card slot
9 Hard-disk drive
10 Security cable slot
11 Battery status indicator
12 Power indicator
13 Touch pad buttons
14 Touch pad
15 Keyboard
