System Board: Dell™ XPS M140 Service Manual
file:///C|/Users/santhosh_v.ASIA-PACIFIC/Desktop/Hawke/New%20folder/sysboard.htm[2/21/2014 11:34:06 AM]
Back to Contents Page
System Board
Dell™ XPS M140 Service Manual
Removing the System Board
Replacing the System Board
Removing the System Board
CAUTION: Before you perform any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as the back panel) on the computer.
The system board's BIOS chip contains the Service Tag, which is also visible on a barcode label on the bottom of the
computer. The replacement kit for the system board includes a CD that provides a utility for transferring the Service
Tag to the replacement system board.
1. Follow the instructions in Preparing to Work Inside the Computer .
2. Remove the hard drive (see Removing the Hard Drive ).
3. Remove the optical drive (see Removing the Optical Drive ).
4. Remove the Mini PCI card, if applicable (see Removing the Mini PCI Card ).
5. Remove the modem, if applicable (see Removing the Modem ).
6. Remove the Bluetooth module, if applicable (see Removing the Bluetooth Module ).
7. Disconnect the cable for the Bluetooth module from the system board.
8. Remove the hinge cover (see Removing the Hinge Cover ).
9. Remove the keyboard (see Removing the Keyboard ).
10. Remove the display assembly (see Removing the Display Assembly ).
11. Remove all memory modules (see Removing a Memory Module ).
12. Remove the micropressor thermal-cooling assembly (see Removing the Microprocessor Thermal- Cooling
Assembly ).
13. Remove the microprocessor module (see Removing the Microprocessor Module ).
