Display Assembly and Display Latch: Dell™ XPS M140 Service Manual
file:///C|/Users/santhosh_v.ASIA-PACIFIC/Desktop/Hawke/New%20folder/display0.htm[2/21/2014 11:33:55 AM]
Display Assembly and Display Latch
Dell™ XPS M140 Service Manual
Display Assembly
Removing the Display Assembly
CAUTION: Before you perform any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as the back panel) on the computer.
1. Follow the instructions in
Preparing to Work Inside the Computer
2. Remove the hinge cover (see
).
).
4. Open the display all the way (180 degrees) so that it rests flat against your work surface.
5. Use the pull-tab to disconnect the display cable from the system board.
6. Remove the Mini PCI antenna cables from the retaining clips on the base of the computer and pull apart the
connectors.
7. Remove the four M2.5 x 5-mm screws (two on each side) that connect the display assembly to the computer.
8. Lift the display assembly straight out of the computer.
