Dell UPS 10000R User Manual
Page 35
35
Installation
|
Two IEC 320-C19
Receptacles
Two Output
Circuit
Breakers
Input Terminal
Block
One IEC 60309
332R6S Receptacle
One IEC 60309
332R6S Receptacle
REPO
Ports
UPS Communication
Bay
RS-232
Port
USB
Port
EBM
Connector
Ground
Screw
One Output
Circuit
Breaker
Load Segment 1 (LS1)
Load Segment 2 (LS2)
DELL10KWOLHV
Figure 25. 10 kW, 230V (DELL10KWOLHV) Rear Panel
