Dell Inspiron 1464 (Early 2010) - Manual (Page 25)

Replacing the Display Hinges
1. Follow the procedures in Before You Begin .
2. Replace the six screws that secure the display hinges to the display cover.
3. Replace the display panel (see Replacing the Display Panel ).
4. Replace the display bezel (see Replacing the Display Bezel ).
5. Replace the display assembly (see Replacing the Display Assembly ).
6. Replace the battery (see Replacing the Battery ).
Back to Contents Page
1 display cover 2 screws (6)
3 display hinges (2)
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
