Dell Inspiron 1464 (Early 2010) - Manual (Page 23)

5. Replace the display bezel (see Replacing the Display Bezel ).
6. Replace the display assembly (see Replacing the Display Assembly ).
7. Replace the battery (see Replacing the Battery ).
Display Cable
Removing the Display Cable
1. Follow the procedures in Before You Begin .
2. Remove the display assembly (see Removing the Display Assembly ).
3. Remove the display bezel (see Removing the Display Bezel ).
4. Remove the display panel (see Removing the Display Panel ).
5. Remove the display cable from the routing guides on the display cover.
Replacing the Display Cable
1. Follow the procedures in Before You Begin .
2. Route the display cable in the routing guides on the display cover.
3. Replace the display panel (see Replacing the Display Panel ).
4. Replace the display bezel (see Replacing the Display Bezel ).
5. Replace the display assembly (see Replacing the Display Assembly ).
6. Replace the battery (see Replacing the Battery ).
Display Panel Brackets
Removing the Display Panel Brackets
1. Follow the procedures in Before You Begin .
2. Remove the display assembly (see Removing the Display Assembly ).
3. Remove the display bezel (see Removing the Display Bezel ).
4. Remove the display panel (see Removing the Display Panel ).
5. Remove the six screws that secure the display panel brackets to the display panel.
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
