Replacing the Display Panel Brackets
1. Follow the procedures in Before You Begin .
2. Replace the six screws that secure the display panel brackets to the display panel.
3. Replace the display panel (see Replacing the Display Panel ).
4. Replace the display bezel (see Replacing the Display Bezel ).
5. Replace the display assembly (see Replacing the Display Assembly ).
6. Replace the battery (see Replacing the Battery ).
Display Hinges
Removing the Display Hinges
1. Follow the procedures in Before You Begin .
2. Remove the display assembly (see Removing the Display Assembly ).
3. Remove the display bezel (see Removing the Display Bezel ).
4. Remove the display panel (see Removing the Display Panel ).
5. Remove the six screws that secure the display hinges to the display cover.
1 display panel 2 screws (6)
3 display panel brackets (2)
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
