Cypress Perform CY7C1561V18 - Manual (Page 21)

CY7C1561V18, CY7C1576V18
CY7C1563V18, CY7C1565V18
Document Number: 001-05384 Rev. *F Page 21 of 28
I
DD
[22]
V
DD
Operating Supply V
DD
= Max,
I
OUT
= 0 mA,
f = f
MAX
= 1/t
CYC
333 MHz x8 1200 mA
x9 1200
x18 1200
x36 1200
300 MHz x8 1100 mA
x9 1100
x18 1100
x36 1100
I
SB1
Automatic Power down
Current Max V
DD
,
Both Ports Deselected,
V
IN
≥ V
IH
or V
IN
≤ V
IL
f = f
MAX
= 1/t
CYC
, Inputs
Static
400 MHz x8 550 mA
x9 550
x18 550
x36 550
375 MHz x8 525 mA
x9 525
x18 525
x36 525
333 MHz x8 500 mA
x9 500
x18 500
x36 500
300 MHz x8 450 mA
x9 450
x18 450
x36 450
Electrical Characteristics
(continued)
DC Electrical Characteristics
Over the Operating Range
[15]
Parameter Description Test Conditions Min Typ Max Unit
[+] Feedback [+] Feedback
