Pin Definitions
Name I/O Description
A
0
, A
1
, A Input-
Synchronous
Address Inputs used to select one of the address locations. Sampled at the rising edge of
the CLK if ADSP or ADSC is active LOW, and CE
1
, CE
2
, and CE
3
[2]
are sampled active. A
1
, A
0
are fed to the two-bit counter..
BW
A
, BW
B
BW
C
, BW
D
Input-
Synchronous
Byte Write Select Inputs, active LOW. Qualified with BWE to conduct Byte Writes to the
SRAM. Sampled on the rising edge of CLK.
GW Input-
Synchronous
Global Write Enable Input, active LOW. When asserted LOW on the rising edge of CLK, a
global Write is conducted (ALL bytes are written, regardless of the values on BW
X
and BWE).
BWE Input-
Synchronous
Byte Write Enable Input, active LOW. Sampled on the rising edge of CLK. This signal must
be asserted LOW to conduct a Byte Write.
CLK Input-
Clock
Clock Input. Used to capture all synchronous inputs to the device. Also used to increment the
burst counter when ADV is asserted LOW, during a burst operation.
CE
1
Input-
Synchronous
Chip Enable 1 Input, active LOW. Sampled on the rising edge of CLK. Used in conjunction
with CE
2
and CE
3
[2]
to select/deselect the device. ADSP is ignored if CE
1
is HIGH. CE
1
is
sampled only when a new external address is loaded.
CE
2
Input-
Synchronous
Chip Enable 2 Input, active HIGH. Sampled on the rising edge of CLK. Used in conjunction
with CE
1
and CE
3
[2] to select/deselect the device. CE
2
is sampled only when a new external
address is loaded.
CE
3
[2] Input-
Synchronous
Chip Enable 3 Input, active LOW. Sampled on the rising edge of CLK. Used in conjunction
with CE
1
and CE
2
to select/deselect the device. Not available for AJ package version. Not
connected for BGA. Where referenced, CE
3
[2]
is assumed active throughout this document for
BGA. CE
3
is sampled only when a new external address is loaded.
OE Input-
Asynchronous
Output Enable, asynchronous input, active LOW. Controls the direction of the I/O pins.
When LOW, the I/O pins behave as outputs. When deasserted HIGH, I/O pins are tri-stated,
and act as input data pins. OE is masked during the first clock of a read cycle when emerging
from a deselected state.
ADV Input-
Synchronous
Advance Input signal, sampled on the rising edge of CLK, active LOW. When asserted, it
automatically increments the address in a burst cycle.
ADSP Input-
Synchronous
Address Strobe from Processor, sampled on the rising edge of CLK, active LOW. When
asserted LOW, addresses presented to the device are captured in the address registers. A
1
,
A
0
are also loaded into the burst counter. When ADSP and ADSC are both asserted, only ADSP
is recognized. ASDP is ignored when CE
1
is deasserted HIGH.
ADSC Input-
Synchronous
Address Strobe from Controller, sampled on the rising edge of CLK, active LOW. When
asserted LOW, addresses presented to the device are captured in the address registers. A
1
,
A
0
are also loaded into the burst counter. When ADSP and ADSC are both asserted, only ADSP
is recognized.
ZZ Input-
Asynchronous
ZZ “Sleep” Input, active HIGH. When asserted HIGH places the device in a non-time-critical
“sleep” condition with data integrity preserved. For normal operation, this pin has to be LOW or
left floating. ZZ pin has an internal pull-down.
DQs, DQP
X
I/O-
Synchronous
Bidirectional Data I/O lines. As inputs, they feed into an on-chip data register that is triggered
by the rising edge of CLK. As outputs, they deliver the data contained in the memory location
specified by the addresses presented during the previous clock rise of the read cycle. The
direction of the pins is controlled by OE. When OE is asserted LOW, the pins behave as outputs.
When HIGH, DQs and DQP
X
are placed in a tri-state condition.
V
DD
Power Supply Power supply inputs to the core of the device.
V
SS
Ground Ground for the core of the device.
V
SSQ
I/O Ground Ground for the I/O circuitry.
V
DDQ
I/O Power Supply Power supply for the I/O circuitry.
MODE Input-
Static
Selects Burst Order. When tied to GND selects linear burst sequence. When tied to V
DD
or
left floating selects interleaved burst sequence. This is a strap pin and should remain static
during device operation. Mode pin has an internal pull-up.
TDO JTAG serial
output
Synchronous
Serial data-out to the JTAG circuit. Delivers data on the negative edge of TCK. If the JTAG
feature is not being utilized, this pin should be disconnected. This pin is not available on TQFP
packages.
