Page 7: Compaq alphaserver gs140

UICK

PECS

Options

DA-10051-00A-008 — 02.28.2000

Compaq AlphaServer GS140

Step 6

−−−−

Storage Adapters/Controllers

−−−−

Optional (continued)

Maximum # Supported

Tru64 UNIX

OpenVMS

PCI/System PCI/System

PCI Fast Wide Differential SCSI Adapter (uses one PCI slot); KZPSA

supports TruCluster Available Server and TruCluster Production

Server

8/64

8/26

KZPSA-BB

SCSI-2 Fast Wide Differential cables; 68-pin male straight-to-68-pin male

right-angle; connects KZPSA-BB Fast Wide Differential SCSI-2 port to

DWZZA-VA or DWZZB-VW or connects to DOC-based BA356 via

BN38C cables to gain additional slot

BN21K-xx

Connects from KZPSA to DWZZB-VW in BA670-AB System cabinet

(rear);

connects from KZPSA to DWZZB-VW in BA671-AA in DWLPB-xx PIU

BN21K-01

Connects from KZPSA to DWZZB-VW in BA670-AB System cabinet

(front)

BN21K-02

Connects from KZPSA to DWZZB-VW in BA670-AB Expansion cabinet

(front or rear)

BN21K-05/10

PCI DSSI adapter, 12 per PCI, (KFPSA and KFMSB not supported on

same DSSI bus)

12/24

KFPSA-AA

External shielded cable (MR/MR connectors); select required length, 09,

16, 25 feet

BC29S-xx

External shielded cable (MR/PS connectors); select required length, 06,

09, 16, 30 feet

BC29R-xx

PCI CI adapter, four per PCI, maximum 26 per system (uses one PCI slot

for adapter and one EISA slot for power only); Note: EISA Bridge

option not required

4/26

CIPCA-AA

Same as CIPCA-AA except uses 2 PCI slots

CIPCA-BA

Computer interconnect cable sets, connects CIPCA to Star Coupler;

select length—10, 20, or 45 m

BNCIA-xx

Step 7

−−−−

External Storage Controllers

−−−−

Optional

• HSZ70 UltraSCSI RAID Array controllers are supported under Tru64 UNIX V4.0B or later, OpenVMS V6.2-1H3

for direct attachments or OpenVMS V7.1-1H1 or later for cluster support.

• HSZ80 UltraSCSI RAID Array controllers are supported under Tru64 UNIX V4.0E or later or OpenVMS V7.1-2

or later

• HSG80 Fibre Channel controllers are supported under Tru64 UNIX V4.0F or OpenVMS V7.2-1 or later
• HSJ50 family of CI Storage Array Controllers is supported under OpenVMS V6.2-1H3 with CIPCA-AA/BA or

CIXCD-AC CI controllers; QB-5C4AA-SA software kits are required for each external cache (one for HSJ50,

two for HSJ52, four for HSJ54).

• Controllers require KZPSA, KZPBA, KFPSA, CIXCD or CIPCA SCSI adapters or controllers, as appropriate
• HSZ70 requires QB-5SBAB-SA/SB for Tru64 UNIX, QB-5SBAC-SA/SB for OpenVMS
Fibre Channel controller (HSG80), includes 2-MB cache expandable to 128 MB and requires

128697-B21 HSG80 ACS V8.4F software kit or 128698-B21 V8.4P software kit for each

HSG80 ordered

380672-B21

UltraSCSI controller (HSZ80), includes 2-MB cache expandable to 32 MB and requires 400569-

001 for Tru64 UNIX or 400571-001 for OpenVMS

400564-B21

UltraSCSI controller (HSZ80), includes 2-MB cache expandable to 128 MB and requires 400569-

001 for Tru64 UNIX or 400571-001 for OpenVMS

400565-B21

StorageWorks UltraSCSI RAID Array controller, includes 64-MB cache expandable to 128 MB and

requires DS-HS35X-BC external cache battery and HSZ70 kit

DS-HSZ70-AH

32-MB cache 6-channel CI array controller with cache battery

HSJ50-AF

128-MB cache 6-channel CI array controller with cache battery

HSJ50-AJ

Dual 64-MB cache CI array controller with cache batteries

HSJ52-AF

Dual 128-MB cache CI array controller with cache batteries

HSJ52-AH

Dual 256-MB cache CI array controller with cache batteries

HSJ52-AJ

Quad 512-MB cache CI array controller with cache batteries

HSJ54-AJ
