Page 11: Compaq alphaserver gs140

UICK

PECS

Options

DA-10051-00A-008 — 02.28.2000

Compaq AlphaServer GS140

Step 9

−−−−

Networks and Communications

−−−−

Optional (continued)

Maximum # Supported

Tru64 UNIX

OpenVMS

PCI/System

PCI-to-ATMworks 155 Mb fibre adapter; Tru64 UNIX and appropriate

patch kits (patch kit 1 for V4.0F; patch kit 2 for V4.0E, patch kit 4

for V4.0D); refer to

http://www.service.digital.com

for patch kit

availability; SN-PBXNP-AC PCI Token Ring adapter not

supported in same system with ATM 155 (DAPBA) adapter; if

ATMworks 351 (DGLPA) NIC card is installed, follow that

adapter’s configuration rules; only one ATM adapter can be

installed on same bus as ATMworks 351 network interface card.

3X-DAPBA-FA

Same as above except UTP

3X-DAPBA-UA

PCI-to-ATMworks 622 Mb fibre adapter; Tru64 UNIX and appropriate

patch kits (patch kit 1 for V4.0F; patch kit 2 for V4.0E, patch kit 4

for V4.0D); refer to

http://www.service.digital.com

for patch kit

availability; SN-PBXNP-AC PCI Token Ring adapter not

supported in same system with ATM 622 (DAPCA) adapter; if

ATMworks 351 (DGLPA) NIC card is installed, follow that

adapter’s configuration rules; only one ATM adapter can be

installed on same bus as ATMworks 351 network interface card.

3X-DAPCA-FA

PCI Asynchronous 4-port adapter, maximum two PBXDA-xx per

system

2/2

PBXDA-AA

PCI Asynchronous 8-port adapter, maximum two PBXDA-xx per

system

2/2

PBXDA-AB

PCI Asynchronous 16-port adapter, maximum two PBXDA-xx per

system

2/2

PBXDA-AC

PCI Synchronous 2-port controller, two PBXDP-xx per system

(requires OpenVMS V7.1-2 or later support at this time)

2/2

PBXDP-AA

PCI Synchronous 4-port controller, two PBXDP-xx per system

(requires OpenVMS V7.1-2 or later support at this time)

2/2

PBXDP-AB

Step 10

−−−−

MEMORY CHANNEL

−−−−

Optional

• MEMORY CHANNEL options are supported on GS140 with Console Firmware V5.3-12 or later and 8400

systems with Console Firmware V5.4-10 or later; Console Firmware is available on CD-ROM (AG-RFCBB-

BE) and the following Web site:

http://ftp.digital.com/pub/Digital/Alpha/firmware/interim/gs60gs140

• Two PCI System Area Network controllers supported per system

Tru64 UNIX Systems
• MEMORY CHANNEL options require Tru64 UNIX V4.0F with TruCluster V1.6 or later
• Each system node in a MEMORY CHANNEL cluster requires a TruCuster Production Server (QB-3RLAQ-KA)

or TruCluster MEMORY CHANNEL (QB-4ZCAQ-AA) software license

• TruCluster MEMORY CHANNEL license (QB-4ZCAQ-AA), normally used for high- performance technical

computing applications, is not required if systems include a TruCluster Production Server license (QB-

3RLAQ-KA)

• The following options are not currently supported with MEMORY CHANNEL: DJ-ML200, CIPCA

OpenVMS Systems
• MEMORY CHANNEL options require OpenVMS V7.1-2 or later and OpenVMS Cluster license (QL-MUZAQ-

AA)

• Two-node clusters can be configured by ordering a CCMAB-AA for each system and 1 BN39B-04 or BN39B-10

cable, cable connects directly to CCMAB-AA in each system

• For three or four system clusters, order one CCMAB-AA adapter and one BN39B-04 or BN39B-10 cable for

each system and one CCMHB-AA hub for the cluster

• CCMHB-AA includes four CCMLB-AA line cards and supports up to four nodes; expansion up to eight system

nodes can be achieved by adding up to four additional CCMLB-AA line cards

• If two or more CCMAB-AA controllers are configured in each system, a second CCMHB-AA hub is required for

clusters with more than two nodes; in two-node clusters the CCMAB-AA may be directly connected.
