Q
UICK
S
PECS
Upgrades
23 DA-10051-00A-008 — 02.28.2000
Compaq AlphaServer GS140
In-Cabinet Upgrades (continued)
In-cabinet CD-ROM
• VAX 7000 requires RRDCD-CA option; CD-ROM requires single-ended SCSI-2 connection from KZMSA-AB in
XMI plug-in unit or KZPBA-CA in
PCI plug-in unit.
• If EISA device support or the RAID Configuration Utility is required, select RRDCD-CA for space to mount
floppy disk drive; floppy drive included with KFE70 or KFE72 option.
• CD-ROM device in StorageWorks shelf operates from PCI SCSI controller; DWZZA-VA is not supported.
• All connections to CD-ROM device will stop at device; additional devices are not supported.
In-cabinet CD-ROM assembly, maximum of one per system; required if no CD-ROM device exists
in system being upgraded; includes CD-ROM device, mounting hardware, BN21H-0H cable
(0.75 m); order longer cable to reach XMI plug-in unit or PCI plug-in unit
RRDCD-CA
In-Cabinet 3-phase Power Expansion
• If VAX/DEC 7000 being upgraded includes one H7263 power regulator, check equivalent power units to
determine if second power regulator is required; see Power Configuration Table.
3-phase 48 VDC power regulator with BBU capability; maximum of three per cabinet; second
regulator may be required to supply adequate power depending on configuration; third regulator
assures N+1 power redundancy and higher availability in the event of power regulator failure.
H7263-AA/AB
Same as H7263-AA/AB except no built-in battery backup (BBU) capability H7263-AC/AD
VAX/DEC 7000 to AlphaServer GS140 In-Cabinet SMP Upgrades
• Maximum of seven SMP modules (14 CPUs); if more than three modules are in system, a minimum of two
separate memory module should be ordered for optimal system performance
One VAX/DEC 7000 CPU module to GS140 6/525 dual-CPU module with OpenVMS SMP
extension license
3X-76UAA-AX
One VAX/DEC 7000 CPU module to GS140 6/525 dual-CPU module with Tru64 UNIX SMP
extension license
3X-76UAB-AX
Two VAX/DEC 7000 CPU modules to GS140 6/525 dual-CPU module with OpenVMS SMP
extension license
3X-76UBA-AX
Two VAX/DEC 7000 CPU modules to GS140 6/525 dual-CPU module with Tru64 UNIX SMP
extension license
3X-76UBB-AX
AlphaServer GS140 SMP Expansion Options
• To add additional GS140 CPUs to upgraded system, order the following:
OpenVMS SMP expansion option; GS140 6/525 dual-CPU module, OpenVMS SMP extension
license
762P1-AX
Tru64 UNIX SMP expansion option; GS140 6/525 dual-CPU module, Tru64 UNIX SMP extension
license
762P2-AX
OpenVMS SMP expansion option; GS140 6/700 dual-CPU module, OpenVMS SMP extension
license
3X-764P1-AX
Tru64 UNIX SMP expansion option; GS140 6/700 dual-CPU module, Tru64 UNIX SMP extension
license
3X-764P2-AX
System Upgrades
AlphaServer 8200/GS60/GS60E to AlphaServer GS140 Upgrades
• Complete box-swap system upgrades follow; system cabinet is replaced; however, existing 8200/GS60/GS60E
CPU, CPU clock module, memory, and I/O modules are transferable − see supported options listed in this
QuickSpec
• Upgrades include GS140 system cabinet with 9-slot system bus, 3-phase power subsystem, PCI Plug-in-Unit
with 12-slot PCI shelf, StorageWorks Wide SCSI shelf for inclusion in PCI Plug-in-Unit, and upgrade
documentation
Dual 8200/GS60/GS60E to GS140 upgrade, Tru64 UNIX DA-75U9A-AC/AD/AE
Dual 8200/GS60/GS60E to GS140 upgrade, OpenVMS DY-75U9A-AC/AD/AE
Note: AC = 60 Hz, 208V, AD = 50 Hz, 380-416V, AE = 50/60 Hz, 202V (Japan)
