Power Configuration Table
21
DA-10051-00A-008 — 02.28.2000
Compaq AlphaServer GS140
AlphaServer GS140 EPU (Equivalent Power Units)–
Power Configuration Table
•
Combining 3-phase and 1-phase power regulators in system configuration is not allowed
•
Use chart to determine need for third power regulator
•
EPU must not exceed 180 (Note: EPUs listed in table based on LPAR tests)
Options
EPU Values
System
Cabinet
Options
Quantity
Total EPU
(Qty times
EPU)
EPU Values
Expansion
Cabinet
Options
Quantity
Total
EPU
(Qty times
EPU)
Expanded Base systems include 2 three phase
power regulators, CPU module, system I/O
module, PCI Plug-in-Unit, memory module
30
1
30
I/O expansion cabinet (H9F00-
BA/BB/BC/JC/JD/JE) includes one power
regulator
1
0
Additional dual 6/525 or 6/700 CPU modules—
762P1-AX, 762P2-AX, 3X-764P1-AX, 3X-764P2-AX
14
Additional dual 5/625 CPU modules—
758P1-AX, 758P2-AX
8
KFTHA-AA System I/O module
3
MS7CC-EA, 1-GB memory
5
MS7CC-FA, 2-GB memory
5
MS7CC-GA, 4-GB memory
5
Add PCI options
DWLPB-AA/AB/BA/BB
1
KZPSA-BB
1
KZPAC-AA/CA/CB
1
KZPBA-CA/CB
1
DE435-AA, DE450-AA, DE500-XA, DE500-xx
1
DEFPA-AB/DB/UB/MB
1
KFE70-AA/KFE72-xx
1
Add EISA options
CXI01-AA/AD
1
Disk and Tape options
8-bit SCSI disk drives
1
16-bit SCSI disk drives
1
TLZ07, TLZ09, TLZ9L, TLZ15-VA SCSI tape drive
1
TZ86, TZ87, TZ88 TZ89 -VA SCSI tape drive
3
DWZZB-VW SCSI signal converter
0
Total
Note: Depending on configuration, system offers integral UPS capability that supports all in-cabinet components for
at least 11 minutes. If UPS support is required for external devices, e.g., console terminals, terminal servers,
printers, and modems, universal UPS can be ordered separately.
