Page 10: Compaq alphaserver gs140

UICK

PECS

Options

DA-10051-00A-008 — 02.28.2000

Compaq AlphaServer GS140

Step 8

−−−−

Storage Devices

−−−−

Optional (continued)

External Storage Devices
The following devices can be added as required:
SW5XX, SW6XX, SW8XX Storage Cabinets
SCSI Disk Drives
Tape Drives

−

TZ87, TZ857

(loader support for Tru64 UNIX available via DECnsr), TZ877, TZ88, TZ885, TZ887,

TSZ07, TLZ09, TKZ9E, TKZ9F, TLZ9L, TKZ6x, TL810, TL812, TL820, TL822, TL826, DS-TL891-NE/NT, DS-

TL892-UA, DS-TL893-BA/AC, DS-TL894-BA, DS-TL896-BA, DS-TLZ10-VA, DS-TL895-xx, TZK10/12/20

Step 9

−−−−

Networks and Communications

−−−−

Optional

• Connection of system to Ethernet requires twisted-pair cable (except when using DE500-FA).
Note: For installed systems with KFTIA I/O modules, KFTIA includes two 802.3/Ethernet ports per module.
PCI LAN Communications Controllers
• Requires DWLPB-xx PCI shelf mount box (one included)
• Maximum six DEFPA-AB/DB/UB/MB FDDIcontrollers (100 Mb/sec) per system
• Each adapter/controller uses one PCI slot

Maximum # Supported

Tru64 UNIX

OpenVMS

PCI/System

PCI 1-port 10/100-Mb Ethernet adapter (Twisted Pair); SN-PBXNP-AC

(Token Ring Adapter) not supported in same system; requires

NHD1 of Tru64 UNIX (UCX V4.2 TCP/IP Services Software not

recommended with DE60* devices; TCP/IP V5.0 is recommended)

8/8

3X-DE600-AA

MultiMode Fiber (MMF) add-on daughter card for use with the 3X-

DE602-AA; Tru64 UNIX NHD2 required

8/8

3X-DE602-FA

Category 5 cross-over cable for point-to-point, unshielded

BN24Q-xx

Category 5 cross-over cable for point-to-point, shielded

BN28Q-03

Category 5 straight through for system to repeater or hub, unshielded

BN25G-xx

Twisted pair, shielded (-03, -04, -07 available lengths)

BN26M-xx

Universal PCI to FDDI controller Fibre

−

Single Attachment Station

(SAS) MultiMode Fibre with SC; requires BN34x SC type

connecting cable

3X-DEFPA-AC

Universal PCI to FDDI controller Fibre

−

Dual Attachment Station (DAS)

MultiMode Fibre with SC; requires BN34x SC type connecting

cable

3X-DEFPA-DC

MultiMode Fibre Optic Duplex cable; SC connector-to-ST connector

BN34A-xx

MultiMode Fibre Optic Duplex cable; SC connector-to-SC connector

BN34B-xx

MultiMode Fibre Optic Duplex cable; SC connector-to-MIC connector

BN34D-xx

Universal PCI to FDDI controller, copper

−

Dual Attachment Station

(DAS) CAT 5 UTP with RJ; , requires BN26x or BN25H connecting

cables

3X-DEFPA-

Universal PCI to FDDI controller Copper

−

Single Attachment Station

(SAS) CAT 5 UTP with RJ; requires BN26x or BN25H connecting

cables

3X-DEFPA-UC

8-pin MP-to-8-pin MP, screened, EIA/TIA category 5 cable

BN26M-xx

8-pin MP-to-8-pin MP, screened, crossover, EIA/TIA category 5 cable

BN26S-xx

3-m unshielded twisted pair RJ45 connectors

BN25H-03

PCI Gigabit Ethernet adapter, does not support network boot; one per

DWLPB

DEGPA-SA
