Q
UICK
S
PECS
Options
19 DA-10051-00A-008 — 02.28.2000
Compaq AlphaServer GS140
Step 20 −−−− Recommended Online Power Protection/UPS Solutions for GS140
• For complete protection, UPS products should be used with data line surge protectors
4-wire RJ45 10BaseT, wall plug-in module, add up to four modules per plug in connection
4N-GA249-CA
17” din rail with 19” rackmount provisions for mounting up to 32 ports, rack or wall mount 4N-GA245-AA
Din rail mount surge protection module, 8-wire RJ45, 10/100BaseT twisted pair UL category 5 4N-GA245-EA
Powerware Plus 3-Phase UPS Models
• All models are hardwired on input and rated 50/60 Hz; North American models are rated 176V-256V in,
100/200V, 120/208V, 127/220V out; international models are rated 380-415V in, 380/220V, 400/230V
415/240V out
UPS Models 15 and 18 kVA
• North America 15 and 18kVA models are hardwired on output with optional plug-in receptacle panel
15kVA/10kW, 10 minutes battery time at full load, two batteries, North America or other 60-Hz
applications
4N-AEAAN-BA
18kVA/12kW, seven minutes battery time at full load, two batteries, North America or other 60-
Hz applications
4N-AEAAP-BA
15kVA/10kW, 16 minutes battery time at full load, two batteries, North America or other 60-Hz
applications
4N-AEAAN-BC
18kVA/12kW, 12 minutes battery time at full load, two batteries, North America or other 60-Hz
applications
4N-AEAAP-BC
15 kVA/10kW, 29 minutes of battery time at full load, three batteries, North America or other 60-
Hz applications
4N-AEAAN-BD
18kVA/12kW, 22 minutes of battery time at full load, three batteries, North America or other 60-
Hz applications
4N-AEAAP-BD
15 kVA/10kW, 10 minutes of battery time at full load, two batteries, international or other 50-Hz
applications, hardwired only
4N-AEAAN-BE
18kVA/12kW, seven minutes of battery time at full load, two batteries, international or other 50-
Hz applications, hardwired only
4N-AEAAP-BE
UPS Models 24 and 36kVA
• Models are hardwired on output with optional 30 pole distribution cabinet, wraparound maintenance by-pass
and input filter; distribution cabinet accepts Square D circuit breakers
36kVA/24kW, five minutes of battery time at full load, one battery, North America or other 60-Hz
applications
4N-AEAAS-AA
24kVA/16kW, 30 minutes of battery time at full load, two batteries, North America or other 60-Hz
applications
4N-AEAAR-AB
36kVA/24kW, 15 minutes of battery time at full load, two batteries, North America or other 60-Hz
applications
4N-AEAAS-AB
24kVA/16kW, 50 minutes of battery time at full load, three batteries, North America or other 60-
Hz applications
4N-AEAAR-AC
36kVA/24kW, 30 minutes of battery time at full load, three batteries, North America or other 60-
Hz applications
4N-AEAAS-AC
15 and 18kVA UPS Receptacle Options, Extended Battery Options (Common configurations shown; other
receptacle options available)
• Choose UPS receptacle option depending on input plug configuration of external storage cabinet used; ESA
10000 requires two L6-30R, SW800 requires two L21-30R, and GS140 Expansion Cabinet requires one L21-
30R
15/18kVA model output receptacle module, two L21-30R, three 5-20R2 4N-AEACM-BK
15/18kVA model output receptacle module, two L6-30R, two L21-30R, one 5-20R2 4N-AEACM-BN
15/18kVA model output receptacle module; Module 1 − two L21-30R and conduit kit for
connecting Module 1 to Module 2; Module 2 − two L21-30R, three 5-20R2
4N-AEACM-PA
Add-on battery cabinet for 15 and 18kVA models; can be added to Model 4N-AEAAN/P-BD −
approximately 12 minutes per cabinet
4N-AEACH-BB
