Baumer CombiTemp - Manual (Page 8)

Page 8 Design and specifi cations subject to change without notice
Installation Manual 5850-008 www.baumerprocess.com
5850-008-UK/2008-04-25/Re
v.
A1
This data sheet ma
y only be reproduced in full.
Application Photos
ø80 mm housing with FlexView Cut through DIN - B housing ø80 mm housing with 2 glands
Gland (blind plug at the rear) FlexTop 2201 temperature transmitter Cover not mounted
Clamp connection G1/2A male nipple connection 3A connection at the rear
Fast response sensor Normal response sensor Fast response sensor
White White Red Red White White Red Red
4-wire Sensors Double Elements
Warning:
One of the wires may not be
connected in case of a 3-wire
connection to the temperature
transmitter
