Footrests—High Mount Bracket (cont.)
POS. ITEM #
DESCRIPTION
QTY ASSY NOTES:
1
18135-1
HIGH MOUNT - TUBE & CLAMP STYL
1
1
ALL 75 DEGREE HANGERS AND 90 DEGREE LATCH
1
18135-2
HIGH MOUNT - TUBE & CLAMP STYL
2
1
ALL 75 DEGREE HANGERS AND 90 DEGREE LATCH
2
18136-L
HIGH MOUNT BRKT 90 POP-UP L
1
1
90 DEGREE POP-UP ONLY
2
18136-R
HIGH MOUNT BRKT 90 POP-UP R
1
1
90 DEGREE POP-UP ONLY
2
18136-2
HIGH MOUNT BRKT 90 POP-UP PR
2
1
90 DEGREE POP-UP ONLY
3
18137-1
HIGH MOUNT BRACKET BASE
1
1
4
18138-1
HIGH MOUNT BRKT SWIVEL BAR
1
1
5
9033-4
SCREW 1/4-20 X 1" BUTTON HEAD
4
1
6
9035-4
SCREW 1/4-20X 1-1/2" BUTTON
4
1
7
9073-4
LOCKNUT 1/4-20 NYLON-THIN
4
1
8
9074-4
WASHER 1/4" FLAT 1/2" OD
4
2
9
20100-1
SPACER SLEEVE TEL FTRST EXT
1
1
10
20101-1
4" TEL FTRST EXT TUBE ONLY
1
1
11
18139-1
HIGH MOUNT TUBE ONLY
1
1
11
18139-2
HIGH MOUNT TUBE ONLY
2
1
12
3024
FRAME CLAMP - ANG ADJ REM FTBD
2
2
INCLUDES INNER AND OUTER CLAMP
13
9023-4
SCREW 1/4-20 X 2” HEX HEAD
4
2
14
9000-4
1” TUBE PLUG
4
2
15
9072-4
LOCKNUT 1/4-20 NYLON
4
2
NOT SHOWN
