14

FREEDOM DESIGNS, INC.

WPCNXT 62013

Armrest—Adjustable Height, Tall (cont.)

POS. ITEM #

DESCRIPTION

QTY ASSY NOTES:

Continued Next Page

1a

10756-L

SNGL PST HT ADJ ARM TL DSK L

1

1

INCLUDES DESK LENGTH ARM PAD

1a

10756-R

SNGL PST HT ADJ ARM TL DSK R

1

1

INCLUDES DESK LENGTH ARM PAD

1a

10756-2

SNGL PST HT ADJ ARM TL DSK PR

2

1

INCLUDES DESK LENGTH ARM PAD

1b

10770-L

SNGL PST HT ADJ ARM TL FL L

1

1

INCLUDES FULL LENGTH ARM PAD

1b

10770-R

SNGL PST HT ADJ ARM TL FL R

1

1

INCLUDES FULL LENGTH ARM PAD

1b

10770-2

SNGL PST HT ADJ ARM TL FL PR

2

1

INCLUDES FULL LENGTH ARM PAD

2a

10758-1

SNGL PST HT ADJ TL UPR DESK

1

1

INCLUDES 14, 18, 24-25a

2a

10758-2

SNGL PST HT ADJ TL UPR DESK

2

1

INCLUDES 14, 18, 24-25a

2b

10772-1

SNGL PST HT ADJ TL UPR FULL

1

1

INCLUDES 14, 18, 24-25b

2b

10772-2

SNGL PST HT ADJ TL UPR FULL

2

1

INCLUDES 14, 18, 24-25b

3

10757-L

SNGL PST HT ADJ TL LWR ASSY L

1

1

INCLUDES POS. 7-12a, 13, 15-16, 19-20, 22

3

10757-R

SNGL PST HT ADJ TL LWR ASSY R

1

1

INCLUDES POS. 7-12b, 13, 15-16, 19-20, 22

3

10757-2

SNGL PST HT ADJ TL LWR ASSY PR

2

1

INCLUDES POS. 7-13, 15-16, 19-20, 22

4

10793-1

SNGL PST HT ADJ ARM RECVR ASSY

1

1

INCLUDES POS. 5-6, 21A, 23

4

10793-2

SNGL PST HT ADJ ARM RECVR ASSY

2

1

INCLUDES POS. 5-6, 21A, 23

5

10759-1

SNGL PST HT ADJ ARM RECVR SCKT

1

1

6

10760-1

SNGL PST HT ADJ ARM RCVR CLAMP

1

1

INNER CLAMP / ALSO TO SPACE ARM OUT

7

10761-1

SNGL PST HT ADJ ARM RCVR TUBE

1

1

8

10763-1

SNGL PST ARM RCVR TUBE CLAMP

1

2

9

10764-1

SNGL PST ARM FRAME REL LEVER

1

1

10a

10765-L

SNGL PST ARM HGT ADJ LEVER L

1

1

10b

10765-R

SNGL PST ARM HGT ADJ LEVER R

1

1

10c

10765-2

SNGL PST ARM HGT ADJ LEVER PR

2

1

LEFT AND RIGHT HEIGHT ADJ LEVER

11

10766-STD

SGL PST ARM TRANSFER TUBE STD

1

1

TUBE MEASURES 7.5L X 6H

12a

10767-L

SGL PST ARM SIDE PANEL STD L

1

1

6L X 6H

12b

10767-R

SGL PST ARM SIDE PANEL STD R

1

1

6L X 6H

12c

10767-2

SGL PST ARM SIDE PANEL STD PR

2

1

6L X 6H

13

10768-1

SNGL PST ARM RCVR TUBE CAP

1

1

14

10769-1

SNGL PST ARM HT ADJ POST STD

1

1

15

9039-4

SNGL PST FRM LTCH SPCR BSHNG

4

2

16

9040-4

SNGL PST ARM FRM LTCH SPRING

4

1

17a

10913

ARM PAD DESK LENGTH 9 1/4"

1

1

17b

10916

ARM PAD FULL LENGTH 13 1/4"

1

1

18

9016-4

SCREW 10-32 X 1-1/4" PAN HD

4

2

19

9057-4

SCREW 10-32 X 3/4" BTN HD

4

2

20

9070-4

SCREW 10-32 X 1 1/4" BTN HD

4

2

21a

9020-4

SCREW-1/4-20 X 1 1/4 HEX HEAD

4

4

21b

9021-4

SCREW 1/4-20 X 1-1/2" HEX HEAD

4

4

22

9086-4

LOCKNUT 10-32 NYLOC

4

4

23

9074-4

WASHER 1/4" FLAT 1/2" OD

4

4
