Page 35
26
FREEDOM DESIGNS, INC.
WPCNXT 62013
Back Canes & Components (cont.)
POS. ITEM #
DESCRIPTION
QTY ASSY NOTES:
1a
13200-1
BK PST STD 90 DEG BND SHT 19"
1
1
INCLUDES POS. 9-11 ONLY
1a
13200-2
BK PST STD 90 DEG BND SHT 19"
2
1
INCLUDES POS. 9-11 ONLY
1b
13201-1
BK PST STD 90 DEG BND MED 23"
1
1
INCLUDES POS. 9-11 ONLY
1b
13201-2
BK PST STD 90 DEG BND MED 23"
2
1
INCLUDES POS. 9-11 ONLY
1c
13202-1
BK PST STD 90 DEG BND TL 26"
1
1
INCLUDES POS. 9-11 ONLY
1c
13202-2
BK PST STD 90 DEG BND TL 26"
2
1
INCLUDES POS. 9-11 ONLY
2a
13203-1
BK PST ERGO BND SHORT 19"
1
1
INCLUDES POS. 9-11 ONLY
2a
13203-2
BK PST ERGO BND SHORT 19"
2
1
INCLUDES POS. 9-11 ONLY
2b
13204-1
BK PST ERGO BND MED 23"
1
1
INCLUDES POS. 9-11 ONLY
2b
13204-2
BK PST ERGO BND MED 23"
2
1
INCLUDES POS. 9-11 ONLY
2c
13205-1
BK PST ERGO BND TALL 26"
1
1
INCLUDES POS. 9-11 ONLY
2c
13205-2
BK PST ERGO BND TALL 26"
2
1
INCLUDES POS. 9-11 ONLY
3
18005-1
BACK CANE RECEIVER ASSEMBLY
1
1
INCLUDES POS. 4, 12-13, 16, 18-21
3
18005-2
BACK CANE RECEIVER ASSEMBLY
2
1
INCLUDES POS. 4, 12-13, 16, 18-21
4
18004-1
BACK CANE RECEIVER BRACKET
1
1
4
18004-2
BACK CANE RECEIVER BRACKET
2
1
5a
17050-N
RIGIDIZING ASSEMBLY - 10-14W
1
1
INCLUDES POS. 6, 7a, 8, 14-15, 17-18
5b
17050-M
RIGIDIZING ASSEMBLY - 12-16W
1
1
INCLUDES POS. 6, 7b, 8, 14-15, 17-18
5c
17050-W
RIGIDIZING ASSEMBLY - 14-18W
1
1
INCLUDES POS. 6, 7c, 8, 14-15, 17-18
5d
17050-X
RIGIDIZING ASSEMBLY - 18-22W
1
1
INCLUDES POS. 6, 7d, 8, 14-15, 17-18
6
16049-1
RIGIDIZING BKRST BAR MNT FITNG
1
1
7a
17051-N
RIGIDIZING CENTER TUBE- 10-14W
1
1
6" LONG, ADJUSTS 10-14W
7b
17051-M
RIGIDIZING CENTER TUBE - 12-16W
1
1
8" LONG, ADJUSTS 12-16W
7c
17051-W
RIGIDIZING CENTER TUBE - 14-18W
1
1
10" LONG, ADJUSTS 14-18W
7d
17051-X
RIGIDIZING CENTER TUBE - 18-22W
1
1
14" LONG, ADJUSTS 18-22W
8
17054-1
RIGIDIZER SIDE TUBE
1
2
9
1998
FOAM GRIP 1" ID X 4.5"
1
1
10
5023-4
STEM BMPR FOR BACKPOST & ARMS
4
1
11
9000-4
TUBE PLUG - 1"
4
1
12
9005-2
PLSTIC SDL 1" FOR 5/16" SCREW
2
1
13
9024-4
SCREW 1/4-20 X 2 1/4" HEX HEAD
4
2
14
9035-4
SCREW 1/4-20 X 1-1/2" BUTTON
4
1
15
9038A-4
SCREW 1/4-20 X 3/8" SET SCREW
4
1
16
9072-4
LOCKNUT 1/4-20 NYLON
4
2
17
9073-4
LOCKNUT 1/4-20 NYLON-THIN
4
1
18
9074-4
WASHER 1/4" FLAT
4
2
19
9081-4
SCREW 5/16-18 X 2 1/4" HEX HEAD
4
1
20
9088-4
LOCKNUT 5/16-18 NYLON-THIN
4
1
21
9090-4
WASHER 5/16" FLAT, THIN
4
2
