Armrests—flip back, telescoping (cont.), 10 freedom designs, inc – Freedom Designs Freedom NXT User Manual
Page 19
10
FREEDOM DESIGNS, INC.
WPCNXT 62013
Armrests—Flip Back, Telescoping (cont.)
POS. ITEM #
DESCRIPTION
QTY ASSY NOTES:
1a
10731-L
F/BK TELE ARM 10.5-13.5" DSK L
1
1
INCLUDES POS. 2, 3a, 4-18 (no pad included)
1a
10731-R
F/BK TELE ARM 10.5-13.5" DSK R
1
1
INCLUDES POS. 2, 3a, 4-18 (no pad included)
1a
10731-2
F/BK TEL ARM 10.5-13.5" DSK PR
2
1
INCLUDES 2 EACH POS 2, 3a, 4-18 (no pad
included)
1b
10752-L
F/BK TELE ARM 10.5-13.5" FL L
1
1
INCLUDES POS. 2, 3b, 4-18 (no pad included)
1b
10752-R
F/BK TELE ARM 10.5-13.5" FL R
1
1
INCLUDES POS. 2, 3b, 4-18 (no pad included)
1b
10752-2
F/BK TELE ARM 10.5-13.5" FL PR
2
1
INCLUDES 2 EACH POS 2-3b, 4-18 (no pads
included)
2
18144-1
F/BK TELES ARM TUBE REAR
1
1
3a
18142-1
ADJUST LCKG ARMRST TUBE DESK
1
1
NEEDED FOR DESK PADS 7.25" LONG
3b
18145-1
ADJUST LCKG ARMRST TUBE FULL
1
1
NEEDED FOR FULL LENGTH PADS 11" LONG
4
6014
F/BCK ARMREST MTG PLATE
1
1
5
6012
F/BACK ARMREST ANG ADJ BARREL
1
1
6
9000-4
TUBE PLUG - 1"
4
1
7
9005-2
PLSTIC SDL 1" FOR 5/16" SCREW
2
1
8
9021-4
SCREW 1/4-20 X 1-1/2" HEX HEAD
4
1
9
9023-4
SCREW 1/4-20 X 2" HEX HEAD
4
1
10
9026-2
SCREW-1/4-20 X 2 3/4" HEX HEAD
2
1
11
9072-4
LOCKNUT 1/4-20 NYLON
4
2
12
9073-4
LOCKNUT 1/4-20 NYLON-THIN
4
3
13
9074-4
WASHER 1/4" FLAT 1/2" OD
4
3
14
9075-4
WASHER 1/4" FLAT-THIN
4
1
15
9089-4
WASHER 5/16" FLAT
4
1
16
9115-4
SCREW 10-32 X 3/8 PHIL PAN HD
4
2
17
9042-4
SCREW 10-32 X 1/2" SET SCREW
4
1
18
9104-4
SCREW 10-32 X 1/4" SOCKET HD
4
1
19a
5021
FOAM ARMREST PAD - 4 1/2"
1
1
19b
5022
FOAM ARMREST PAD - 9 1/2"
1
1
19c
10916
ARM PAD FULL LENGTH 13 1/4"
1
1
19d
10913
ARM PAD DESK LENGTH 9 1/4"
1
1
