22

FREEDOM DESIGNS, INC.

WPCNXT 62013

Armrests—Dual Post Flip Back Adjustable Height (cont.)

POS. ITEM #

DESCRIPTION

QTY ASSY NOTES:

1a

18113-L

DL PST ADJ HGT F/U DSK CMPL L

1

1

INCLUDES POS. 5, 7a, 8-13, 15-21

1b

18113-R

DL PST ADJ HGT F/U DSK CMPL R

1

1

INCLUDES POS. 5, 7b, 8-13, 15-21

1

18113-2

DL PST ADJ HGT F/U DSK CMPL PR

2

1

INCLUDES POS. 5, 7, 8-13, 15-21

2a

18114-L

DL PST ADJ HGT F/U FL CMPL L

1

1

INCLUDES POS. 6-7a, 8-12, 14-21

2b

18114-R

DL PST ADJ HGT F/U FL CMPL R

1

1

INCLUDES POS. 6-7b, 8-12, 14-21

2

18114-2

DL PST ADJ HGT F/U FL CMPL PR

2

1

INCLUDES POS. 6-12, 14-21

3a

18115-L

DL PST ADJ HGT F/U DSK ASSY L

1

1

INCLUDES POS. 5, 7a, 13, 15, 18

3b

18115-R

DL PST ADJ HGT F/U DSK ASSY R

1

1

INCLUDES POS. 5, 7b, 13, 15, 18

3

18115-2

DL PST ADJ HGT F/U DSK ASSY PR

2

1

INCLUDES POS. 5, 7a, 7b, 13, 15, 18

4a

18116-L

DL PST ADJ HGT F/U FL ASSY L

1

1

INCLUDES POS. 6, 7a, 14-15, 18

4b

18116-R

DL PST ADJ HGT F/U FL ASSY R

1

1

INCLUDES POS. 6, 7b, 14-15, 18

4

18116-2

DL PST ADJ HGT F/U FL ASSY PR

2

1

INCLUDES POS. 6, 7a, 7b, 14-15, 18

5

18117-1

DL PST ADJ HGT UPR TUBE DSK

1

1

5

18117-2

DL PST ADJ HGT UPR TUBE DSK

2

1

6

18118-1

DL PST ADJ HGT UPR TUBE FL

1

1

6

18118-2

DL PST ADJ HGT UPR TUBE FL PR

2

1

7a

18119-L

DL PST ADJ HGT LWR ASSY L

1

1

7b

18119-R

DL PST ADJ HGT LWR ASSY R

1

1

7

18119-2

DL PST ADJ HGT LWR ASSY PR

2

2

8

18120-1

DL PST F/U ARM RR RCVR SOCKET

1

1

8

18120-2

DL PST F/U ARM RR RCVR SOCKET

2

1

9a

18121-L

DL PST F/U RR RCVR MTG PLT L

1

1

9b

18121-R

DL PST F/U RR RCVR MTG PLT R

1

1

9

18121-2

DL PST F/U RR RCVR MTG PLT PR

2

1

10a

18107-L

DUAL POST ARM FRNT RECEIVER L

1

1

INCLUDES POS. 10a, 19, 21

10b

18107-R

DUAL POST ARM FRNT RECEIVER R

1

1

INCLUDES POS. 10b, 19, 21

10

18107-2

DUAL POST ARM FRNT RECEIVER PR

2

1

INCLUDES POS. 10a, 10b, 19, 21

11

9074A-4

FLAT WASHER 1/4" LARGE O.D.

4

1

12

18122-1

DETENT PIN WITH LANYARD

1

1

13

10913

ARM PAD DESK LENGTH 9 1/4"

1

1

14

10916

ARM PAD FULL LENGTH 13 1/4"

1

1

15

3099-4

TUBE PLUG - 3/4"

4

1

16

9024-4

SCREW 1/4-20 X 2-1/4" HEX HD

4

2

17

9048-4

SCREW 1/4-20 X 1-1/4" FLAT HD

4

1

18

9106-4

SCREW 10-32 X 1-1/4 PHIL PN HD

4

2

19

9072-4

LOCKNUT 1/4-20 NYLON

4

2

20

9073-4

LOCKNUT 1/4-20 NYLON-THIN

4

1

21

9074-4

WASHER 1/4" FLAT 1/2" OD

4

6

22a

18123-L

DL PST F/U ARM RCVR ASSY RR L

1

1

INCLUDES POS. 8-9a, 11-12, 16-17, 20-21

22b

18123-R

DL PST F/U ARM RCVR ASSY RR R

1

1

INCLUDES POS. 8-9b, 11-12, 16-17, 20-21

22

18123-2

DL PST F/U ARM RCVR ASSY RR PR

2

1

INCLUDES POS. 8-9a, 9b 11-12, 16-17, 20-21

23a

18124-L

DL PST F/U ARM RCVRS FRT/ RR L

1

1

INCLUDES POS. 8-9a, 10-12, 16-17, 20-21

23b

18124-R

DL PST F/U ARM RCVRS FRT/ RR R

1

1

INCLUDES POS. 8-9b, 10-12, 16-17, 20-21

23

18124-2

DL PST F/U ARM RCVRS FR/RR PR

2

1

INCLUDES POS. 8-9a, 9b 10-12, 16-17, 20-21
