12

FREEDOM DESIGNS, INC.

WPCNXT 62013

Armrests—Flip Back, Telescoping-Locking (cont.)

POS. ITEM #

DESCRIPTION

QTY ASSY NOTES:

1a

18140-L

LKG F/BK TEL ARM 10.5-13.5 D L

1

1

INCLUDES POS. 2, 3a, 4-5a, 6-17 (no pad included)

1a

18140-R

LKG F/BK TEL ARM 10.5-13.5 D R

1

1

INCLUDES POS. 2, 3a, 4-5b, 6-17 (no pad included)

1a

18140-2

LK F/BK TEL ARM 10.5-13.5 D PR

2

1

INCLUDES 2 EACH POS. 2, 3a, 4-17 (no pad

included)

1b

18143-L

LKG F/BK TEL ARM 10.5-13.5 F L

1

1

INCLUDES POS. 2, 3b, 4-5a, 6-17 (no pad included)

1b

18143-R

LKG F/BK TEL ARM 10.5-13.5 F R

1

1

INCLUDES POS. 2, 3b, 4-5b, 6-17 (no pad included)

1b

18143-2

LK F/BK TEL ARM 10.5-13.5 F PR

2

1

INCLUDES 2 EACH POS. 2, 3b, 4-17 (no pad

included)

1c

18147-L

LKG F/BK TELE ARM 17-20" L

1

1

INCLUDES POS. 2, 3c, 4-5a, 6-17 (no pad included)

1c

18147-R

LKG F/BK TELE ARM 17-20" R

1

1

INCLUDES POS. 2, 3c, 4-5b, 6-17 (no pad included)

1c

18147-2

LKG F/BK TELE ARM 17-20" PR

2

1

INCLUDES 2 EACH POS. 2, 3c, 4-17 (no pad

included)

2

18141-1

LCKNG TLSCPNG ARM REAR ASSY

1

1

3a

18142-1

ADJUST LCKG ARMRST TUBE DESK

1

1

NEEDED FOR DESK PADS 7.25" LONG

3b

18145-1

ADJUST LCKG ARMRST TUBE FULL

1

1

NEEDED FOR FULL LENGTH PADS 11" LONG

3c

18146-1

ADJUST LCKG ARMRST TUBE 17-20

1

1

NEEDED FOR 17-20 L FULL PADS ONLY 14" LONG

4

6014

F/BCK ARMREST MTG PLATE

1

1

5a

6004-L

LKG F/BCK ARM ADJ PLATE - L

1

1

5b

6004-R

LKG F/BCK ARM ADJ PLATE - R

1

1

5c

6004-2

LKG F/BCK ARM ADJ PLATE - PR

2

1

6

9000-4

TUBE PLUG - 1"

4

1

7

9005-2

PLSTIC SDL 1" FOR 5/16" SCREW

2

1

8

9022-4

SCREW-1/4-20 X 1 3/4" HEX HEAD

4

2

9

9023-4

SCREW 1/4-20 X 2" HEX HEAD

4

1

10

9104-4

SCREW 10-32 X 1/4" SOCKET HD

4

1

11

9072-4

LOCKNUT 1/4-20 NYLON

4

1

12

9073-4

LOCKNUT 1/4-20 NYLON-THIN

4

2

13

9074-4

WASHER 1/4" FLAT 1/2" OD

4

1

14

9075-4

WASHER 1/4" FLAT-THIN

4

5

15

9089-4

WASHER 5/16" FLAT

4

1

16

9115-4

SCREW 10-32 X 3/8 PHIL PAN HD

4

2

17

9042-4

SCREW 10-32 X 1/2" SET SCREW

4

1

18

5023-4

STEM BMPR FOR BACKPOST & ARMS

4

1

19a

5021

FOAM ARMREST PAD - 4 1/2"

1

1

19b

5022

FOAM ARMREST PAD - 9 1/2"

1

1

19c

10916

ARM PAD FULL LENGTH 13 1/4"

1

1

19d

10913

ARM PAD DESK LENGTH 9 1/4"

1

1
