Wheel locks—foot activated drum (cont.), 108 freedom designs, inc – Freedom Designs Freedom NXT User Manual
Page 117
108
FREEDOM DESIGNS, INC.
WPCNXT 62013
Wheel locks—Foot Activated Drum (cont.)
32
9125-4
NUT 10MM JAM NUT ZINC
4
1
33
18550-1
FOOT ACTIV BRAKE CABLE 15" L
1
1
LEFT CABLE ONLY ALL WIDTHS
34
18551-1
FT ACTIV BRK CBL 20" 10-12W R
1
1
RIGHT CABLE 10-12W FRAMES
34
18552-1
FT ACTIV BRK CBL 25" 13-16W R
1
1
RIGHT CABLE 13-16W FRAMES
34
18553-1
FT ACTIV BRK CBL 30" 17-20W R
1
1
RIGHT CABLE 17-20W FRAMES
35
18002-1
NXT AXLE PLATE MTG BRKT
1
1
36
18003-1
NXT AXLE PLATE MTG BRKT CLMP
1
1
37
9037-4
SCREW 1/4-20 X 2" BUTTON HD
4
2
38
9128-4
SCREW 1/4-20 X 2-1/4" BHCS
4
1
39
9122-4
SCREW 1/4-20 X 7/8” FLAT HEAD
4
2
40
9062-4
SCREW 1/4-20 X 1 1/4" SKT HEAD
4
2
41
9073-4
LOCKNUT 1/4-20 NYLON-THIN
4
3
42
9074-4
WASHER 1/4" FLAT 1/2" OD
4
6
POS. ITEM #
DESCRIPTION
QTY ASSY NOTES:
