Armrest—Adjustable Height, Short
STANDARD SEAT WIDTH REQUIRES (1)INNER CLAMP (ITEM 5)
AND USES 1-1/4” LONG MOUNTING SCREW (ITEM 24a)
EXTENDED SEAT WIDTH REQUIRES (2) INNER CLAMPS AS
SHOWN AND USES 1-1/2” LONG MOUNTING SCREWS (ITEM 24b)
