Cross Brace Components - Folding Frames
FRAME
WIDTH
CROSS
BRACE ARM
LENGTH “A”
CROSS BRACE
TUBE LENGTH
“A”
10-12 W
3-7/8”
9-3/16” (NOTCHED)
11-13 W
4-3/8”
9-3/4”
12-14 W
4-13/16”
10-1/8”
13-15 W
5-1/4”
11”
14-16 W
5-3/4”
11-1/4”
15-17 W
6-1/4”
11-13/16”
16-18 W
6-11/16”
12-11/16”
17-18 W
6-11/16”
12-11/16”
18W
6-11/16”
14-1/2”
19W
7-3/8”
15-1/2”
20W
7-5/8”
16-1/2”
