FREEDOM DESIGNS, INC.

107

WPCNXT 62013

Wheel locks—Foot Activated Drum (cont.)

POS. ITEM #

DESCRIPTION

QTY ASSY NOTES:

1

18500-2

FOOT ACTIV DRUM W/L ASSY NXT

1

1

ALL WHEEL SIZES BEFORE 2/28/2013 / EFFECTIVE

3/1/2013 ALL BUT 16 & 18 WHEELS

1

18501-2

FT ACTV DRM W/L ASSY NXT 16/18

1

1

DRUM WHEEL LOCK 16 & 18” WHEELS ONLY

(EFFECTIVE 3/1/2013)

2

18510-1

FOOT LEVER ASSY - DRUM W/LOCK

1

1

3

18511-1

CABLE ACCESS COVER

1

2

4

9126-4

SCREW 10-32 X 3/8" BHCS

4

2

5

18512-1

CABLE ANCHOR PLATE STNLS

1

2

6

9127-4

SCREW 10-32 X 3/8" SOCKET

4

2

7

18513-1

CABLE FERRULE - SLOTTED

1

2

8

18514-1

FOOT LEVER MOUNTING BRACKET

1

1

9

18515-1

FT MECH MTNG BRKT SPCR

1

1

10

9021-4

SCREW 1/4-20 X 1-1/2" BHCS

4

1

11

9033-4

SCREW 1/4-20 X 1" BHCS

4

2

12

5016B

FOAM GRIP 3/4" X 2"

13

18527-1

AXLE Q/R 4-5/8 X 1/2" DRUM LOC

1

1

FOR ALL WHEELS EFFECTIVE 3/1/2013

13

18527-2

AXLE Q/R 4-5/8 X 1/2" DRUM LOC

2

1

FOR ALL WHEELS EFFECTIVE 3/1/2013

14

18528-1

AXLE Q/R 5" X 1/2" DRUM LOC

1

1

DRUM BRAKE FOR 16 & 18" WHEELS ONLY UNTIL

2/28/2013

14

18528-2

AXLE Q/R 5" X 1/2" DRUM LOC

2

1

DRUM BRAKE FOR 16 & 18" WHEELS ONLY UNTIL

2/28/2013

15a

18530-L

DRUM BRAKE & LOCK MECHANISM L

1

1

15b

18530-R

DRUM BRAKE & LOCK MECHANISM R

1

1

15

18530-2

DRUM BRAKE & LOCK MECHANISM PR

1

1

16

18531-L

DRUM BRAKE MECH MNTNG PLATE L

1

1

16

18531-R

DRUM BRAKE MECH MNTNG PLATE R

1

1

17

18532-1

DRUM BRAKE AXLE PLATE

1

1

18a

18533-1

DRUM BRAKE AXLE SLEEVE 2-3/4"

1

1

18b

18534-1

DRUM BRAKE AXLE SLEEVE 2-1/4"

1

1

16 & 18" WHEELS ONLY / EFFECTIVE 3/1/2013

19

18535-1

AXLE SLEEVE SPACER 5/16 X 3/4"

1

1

20

9121-4

NUT 3/4-16 JAM NUT ZINC

4

1

21

18536-2

DRUM BRAKE - W/L SHOE SET

1

1

ONE SET DOES ONE WHEEL

22

18537-1

DRUM BRAKE SHOE RETURN SPRING

1

1

23

18538-1

DRUM BRAKE SHOE BACKING SPACER

1

1

24

18539-1

DRUM BRAKE SHOE CAM

1

1

25

18540-1

DRUM BRAKE SHOE CAM ARM

1

1

26

9122-4

SCREW 5MM X 8MM BHCS

4

1

27

18542-1

BRAKE SHOE RETAINER CLIP

1

1

28

18543-1

CABLE ANCHOR BOLT

1

1

29

9123-4

WASHER 6MM ID CHROME FLAT

4

2

30

9124-4

NUT 10MM CHROME LOCK NUT

4

1

31

18544-1

CABLE END ADJ FITTING - DRUM BRAKE

1

1

10MM WRENCH FOR ADJUSTMENT

Continued Next Page
