Calibration – Humboldt HM-3000.3F Digital MasterLoader User Manual
Page 24
Calibration
This menu item is used to calibrate or verify the calibration of the HM-3000.
WARNING: Calibration should only be performed by trained
personnel with proper, certified equipment. The HM-3000 and
its instrumentation should be calibrated once a year or as the need
arises.
Channel Calibration
To calibrate a channel, press
You should see this screen:
Press
you will see this screen:
Press
(ENGINEERING SETUP). You should see this screen:
Press
(CALIBRATION) You will be asked for a password, enter:
You should see this screen:
* REVIEW LAST TEST
* RUN TEST
* MORE SETUP
* ENGINEERING SETUP
* SENSOR LIMITS OFF
* RAW_DATA
* MORE SETUP
* CONFIGURATION
* CALIBRATION
* LOGGING INTERVAL
21
CALIBRATION screen
* SELECT CHANNEL “CH1”
* CALIBRATION CHANNEL
* CLEAR CALIBRATION
