Press
(SENSOR MAX) to move between the numbers. Keep pressing
until the digit you want to change is flashing. Once you have
selected the number you want to change, press
(INCREASE) or
(DECREASE) to change the number to the desired value. Below is a
configuration chart for Humboldt instrumentation. These are the numbers
that correspond to each Humboldt sensors.
Load Cell
Part#
English Max (lbf)
Metric Max (kN)
10,000 lb. (50kN)
HM-2300.100
010000
050.00
5,000 lb. (25kN)
HM-2300.050
005000
025.00
2,000 lb. (10kN)
HM-2300.020
2000.0
10.000
1,000 lb. (5kN)
HM-2300.010
1000.0
05.000
500 lb. (2.5kN)
HM-2300.005
0500.0
02.500
LVDT Transducer
Part#
English Max (in.)
Metric Max (mm)
0.4" (10.0mm)
HM-2310.04
0.4000
10.000
1.0" (25.4mm)
HM-2310.10
01.000
25.000
2.0" (50.8mm)
HM-2310.20
02.000
50.000
Pore Pressure
Part#
English Max (psi) Metric Max (kPa)
100psi (1000kPa)
HM-2300.100
0100.0
001000
To return to any prior screen you can always press
Channel Test Configuration
In order to perform a test, channels must be configured for the specific test
you wish to run. To configure a channel for a test, press
You should
see this screen:
Press
you will see this screen:
* REVIEW LAST TEST
* RUN TEST
* MORE SETUP
* ENGINEERING SETUP
* SENSOR LIMITS OFF
* RAW_DATA
* MORE SETUP
