Bio-Rad Econo Gradient Pump Kits User Manual
Page 38
4. The fuse socket in the fuse drawer is removable. Turn the socket
such that the correct voltage shows through the window.
5. Reinsert the fuse drawer into the power entry module, with the
locking tab to the left. Press gently until it snaps into place.
6. Insert the power cord plug into the power entry module. Plug the
power cord into a properly grounded outlet.
Figure 7-1. Fuse Replacement and Voltage Conversion.
Maintenance
34
110
220
Power Entry Module
Voltage Selector
Window
Fuse Drawer
4006161B.qxd 8/14/2003 8:09 AM Page 34
