5.5 RUNNING A PROGRAM
To start a program (be sure to enter the Program mode by using the
Mode key), press the Run key. This will start the run. By using the
right soft key, the Run screen can show time elapsed or time
remaining on the run. If program steps are in volume, elapsed or
remaining volume will also be displayed.
Time elapsed Time remaining
__m: __s __mm: __s
__ml elapsed __ml left
Pressing the Next key will show the current gradient conditions:
with Mixer and Diverter valve with Mixer and Splitter valve
ml/m %B Divert ml/m %B Split
If the program is allowed to finish normally, the Econo Gradient Pump
beeps and displays the following screen:
Program Finished
Pressing any key will put the Econo Gradient Pump into Manual
mode.
The run may be interrupted by pressing the Next key twice. Doing so
brings up the following screen:
Hold Pause Abort
System Operation
