Display Function
Aux Valve Connector
This 8-pin connector controls auxiliary
valves such as the optional SV-3 Diverter
valve or the optional Splitter valve.
I/O Connector
This 8-pin outlet provides start signals to the
Model 1327 Chart Recorder, the Model 2110
Fraction Collector, or the Model 2128
Fraction Collector. Simultaneous control of
both the Model 2110 and the Model 1327, or
the Model 2128 and the Model 1327, can be
accomplished via the 2110-Y cable and the
2128-Y cable respectively. I/O connector
pinouts are given in Appendix B. A TTL input
is also present which allows the pump to be
started remotely.
[base; see figure 3-2] The underside of the Econo Gradient Pump
contains the power switch.
