3.0 USING THE QUADTEC WITH THE BIOLOGIC HR SYSTEM
The QuadTec UV/Vis detector provides a powerful addition to the analytical capabilities of the BioLogic HR
system. The QuadTec can simultaneously monitor two different wavelengths when connected to the BioLogic
HR via two SIM-HR modules.
Figure 3-1. QuadTec with the BioLogic HR System
USE WITH THE BIOLOGIC HR SYSTEM SYSTEM INSTALLATION AND SETUP
3-1
CONTROLLER WORKSTATION MODEL 2128 FRACTION
COLLECTOR
UNO Q-1 COLUMN
AV7-3
INJECT
VALVE
QUADTEC DETECTOR
SIM MODULES
