1.3 Specifications
These specifications pertain to the complete CHEF-DR II system. A system including
the Model 1000 Mini Chiller is also available.
CHEF-DR II Specifications
Drive Module
Dimensions 26 (depth) x 43 (width) x 14 (height) cm
Construction Aluminum chassis
Weight 7.8 kg
Maximum voltage 250 VDC
Maximum current 500 mA
Electrode potentials Dynamically regulated (feedback adjustment)
+/- 0.5%
Input voltage range 90-132 VAC/47-63 Hz/0.7 amps (maximum)
198-264 VAC/47-63 Hz/0.35 amps (maximum)
Fuses 0.5 amp Fast Blow for high voltage output (front panel)
1.0 amp Slow-Blow (100/120 V) or
0.5 amp Slow-Blow (220/240 V)
Environmental
Operating 50 °F (10 °C) to 90 °F (32 °C) temperature 30-80%
humidity
Storage 32 °F (0 °C) to 140 °F (60 °C) temperature 10-90%
humidity
Control Module
Dimensions 13.5 (depth) x 31 (width) x 17 (height) cm
Maximum current 500 mA
Allowable voltage gradients 0.6 - 6 V/cm, in 0.1 V/cm increments
Data entry Keyboard
Power supply 250 V maximum, to allow maximum gradient of
6 V/cm,continuously adjustable
Functional
Switching range 0.1 sec to 65,000 sec (all electronic switching)
Maximum program blocks 2, with automatic execution
Maximum run time 999 hours per block
Input voltage range 90-132 VAC/47-63 Hz/1.7 amps (maximum)
198-264 VAC/47-63 Hz/0.85 amps (maximum)
Fuses 2.0 amp Slow-Blow (100/120 V) or
1.0 amp Slow-Blow (220/240 V)
Environmental
Operating 50 °F (10 °C) to 90 °F (32 °C) temperature 30-80%
humidity
Storage 32 °F (0 °C) to 140 °F (60 °C) temperature 10-90%
humidity
Electrophoresis cell
Dimensions 43 (depth) x 44 (width) x 11 (height) cm, horizontal format
Construction Acrylic
Lid Safety interlocked
Weight 8.5 kg
Electrodes 24, platinum (0.01 inch diameter)
Temperature monitoring Via precision temperature probe mounted through lid
(optional)
