A-4 ADS Model 4000 Manual
Drift 0.0 inches
Cable Standard size: 35.0 feet (10.67 m) long x 0.50
inches (1.27 cm) diameter
Pressure Depth Sensor
Enclosure Streamlined molded epoxy
Dimensions 5.0 inches (12.7 cm) long x 1.36 inches (3.45 cm)
wide x 1.0 inch (2.54 cm) high
Range 0.0 to 5.0 psi: up to 11.5 feet (3.5 m)
0.0 to 15.0 psi: up to 34.5 feet (10.5 m)
0.0 to 30.0 psi: up to 69.0 feet (21.0 m)
Accuracy 0.2% of full scale for these ranges:
0.1-5.0 psi: 0.25-11.5 feet (0.08-3.5 m)
0.1-15.0 psi: 0.25-34.5 feet (0.08-10.5 m)
1.0-30.0 psi: 2.3-69.0 feet (0.7-21.0 m)
Resolution 0.025% of full scale
Cable Standard size: 40 feet (12.2 m) long x 0.30 inches
(0.76 cm) diameter
Depth Board
Processor 80C320 CMOS microprocessor
Memory EPROM: 64K bytes
RAM: 32K bytes
Communication UART (to communicate over a logic-level bus with
the processor)
