Preparation 7
12/09/2009 195-068Q
Tools Required
• Forklift, loader or overhead hoist with a capacity of:
Wide Load unload: 13,500 pounds (6124 kg)
Legal Load unload: 3732 pounds (1693 kg)
Legal Load assemble: 2535 pounds (1150 kg)
• A tractor of sufficient size and horsepower with at
least two remote hydraulic circuits. Refer to “Specifi-
cations and Capacities” in the Operator’s Manual.
• General hand tools
• Jack stands or blocks and safety chain
Note: You will need about 4.5 gallons of hydraulic oil to
refill the tractor hydraulic reservoir after initial
bleeding and cycling of the hydraulic systems.
Pre-Assembly Checklist
1. Read and understand “Important Safety Informa-
tion” on page 1 before assembling.
2. Have at least two people on hand while assembling.
3. Make sure the assembly area is level and free of
obstructions (preferably an open concrete area).
Allow room for wing unfolding and any markers (See
“Position for Assembly” on page 8).
4. Have all major components accounted for.
5. Have all fasteners and pins shipped with implement.
6. Have a copy of the implement Parts Manual (195-
068P) on hand. If unsure of proper placement or
use of any part or fastener, refer to the parts man-
ual.
7. Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
8. Check that all factory-applied safety labels and
reflectors are correctly located and legible. Replace
if improperly located or damaged. Refer to Safety
Decals, in the “Important Safety Information” sec-
tion of the implement Operator’s Manual.
Note: Some decals are dealer installed, to prevent
decal damage during disassembled shipment.
9. Inflate tires to recommended pressure as listed on
the “Tire Inflation Chart” on page 38.
10. Tighten wheel bolts as specified on “Torque Values
Chart” on page 39.
If a pre-assembled part or fastener is temporarily removed,
remember where it goes. Keep the parts separated.
