66 YP825AR Table of Contents Metric Charts Great Plains Manufacturing, Inc.
Liquid Fertilizer Rate
The YP825AR planter supports an optional liquid or dry
fertilizer system. Rate setting for the dry fertilizer system
begins on page 50.
Note: Great Plains recommends checking with your local
Agronomist as soil conditions vary. Soil conditions
in your area may need lesser or more amounts of
fertilizer than represented in these charts. For
in-furrow applications, do not exceed
12 gallons per acre or 112 liters per hectare in any
case.
Liquid Rate Setting Steps
1. Determine application rate desired.
2. Determine sprocket paring and pump adjuster
setting required to provide that rate. Use any of the
following resources:
Set Rate Range
3. Check the current sprocket setup:
Low Range uses the 15T sprocket as Driving, and
also as Driven .
High Range uses the 47T sprocket as Driving, and
the 15T sprocket as Driven.
4. To change Range, loosen the idler , and remove
the pins on the sprocket shafts. Exchange sprockets
by selecting ones from the sprocket storage stob
.
Re-pin. Re-engage idler for
3 ⁄
8
inch (9 mm) slack in
the lower chain span.
• use the web calculator on the CDS-John Blue web
site www.cds-johnblue.com/flow-rate-calculator.shtml
The table on page 70 provides data required.
• use the pre-computed tables starting on page 71
• use the CDS-John Blue 112718-01 slide chart
provided with the pump. Use the sprocket ratios
and loaded radius shown in the table on page 77.
The values in this table have been adjusted to
ease use of the chart.
34713
Great Plains Manufacturing, Inc.
Fertilizer Rate
41
01/26/2010
401-651B
Char t Fer tilizer Rate These char ts sho w pre-computed application r
ates f or
each half step of pump setting. If a r
ate sho wn on this
char t is sufficiently close to y
our desired field r
ate, use
the T ransmission sproc
ket and Pump Setting v
alues to
configure y our planter
. If you need to set metr
ic rates , use the CDS-JohnBlue
web calculator (see page
42). If using the slide char
t or w eb methods to set y
our r ate,
use the char ts on this page to quic kly deter mine whether
you need the Lo
w or High Range tr
ansmission sproc
ket
paring.
Null4:
s e t a R r e z i l i t r e F e l p m a S
s e t a R r e z i l i t r e F e l p m a S
e g n a R h g i H
e g n a R w o L
A 5 2 8 P Y A 5 2 6 P Y A 5 2 4 P Y
A 5 2 8 P Y A 5 2 6 P Y A 5 2 4 P Y Planter
-0430
-0630
-0830
Planter
-0430
-0630
-0830
Models
-08TR
-12TR
-16TR
Models
-08TR
-12TR
-16TR
Sprockets
Drive
Driven
Sprockets
Drive
Driven
Transmission
19T
44T
Transmission
44T
19T
p m u P
p m u P Setting
Application Rate (Gallons/Acre)
Setting
Application Rate (Gallons/Acre)
2.0
2.6
1.7
1.3
2.0
14.1
9.4
7.0
2.5
3.3
2.2
1.6
2.5
17.6
11.7
8.8
3.0
3.9
2.6
2.0
3.0
21.1
14.1
10.5
3.5
4.6
3.1
2.3
3.5
24.6
16.4
12.3
4.0
5.2
3.5
2.6
4.0
28.1
18.7
14.1
4.5
5.9
3.9
2.9
4.5
31.6
21.1
15.8
5.0
6.6
4.4
3.3
5.0
35.1
23.4
17.6
5.5
7.2
4.8
3.6
5.5
38.7
25.8
19.3
6.0
7.9
5.2
3.9
6.0
42.2
28.1
21.1
6.5
8.5
5.7
4.3
6.5
45.7
30.5
22.8
7.0
9.2
6.1
4.6
7.0
49.2
32.8
24.6
7.5
9.8
6.6
4.9
7.5
52.7
35.1
26.4
8.0
10.5
7.0
5.2
8.0
56.2
37.5
28.1
8.5
11.1
7.4
5.6
8.5
59.7
39.8
29.9
9.0
11.8
7.9
5.9
9.0
63.3
42.2
31.6
9.5
12.5
8.3
6.2
9.5
66.8
44.5
33.4
10.0
13.1
8.7
6.6
10.0
70.3
46.9
35.1
d n u o r G
d n u o r G
d e e p S
d e e p S
above 2 m
ph>
between 2 and 8.8 mph>
Driving
Driven
2
3
1
4
Figure 29
Fertilizer Drive
31971
1
2
1
2
3
4
