94 2025A/2525A Table of Contents Index Great Plains Manufacturing, Inc.
118-999M Table of Contents Index 2013-06-04
Chain Routing
25AP Final Meter Drive
25AP: Meter Drive (Front type)
Note: No idlers on mount.
top chain passes over single idler on shank
be sure to reconnect idler spring
25AP: Meter Drive (Mid type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
25AP: Meter Drive (Rear type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
Legend:
Sprocket or idler Tooth count
Chain Pitch count
Direction of chain in motion
34T
56P
1
2
0
29619
19T
94P
12T
0
1
2
4
3
2
29620
19T
120
12T
4
3
2
29621
19T
148
12T
2
3
4
2
3
4
