Page 50: Wash water sealer setup (np3000a)
46
NP3000 and NP3000A
Great Plains Manufacturing, Inc.
407-613M
2014-04-22
SCS 450 Setup Data
Wash Water
Refer to Figure 20
Empty the 10 gallon applicator First Aid Water tank.
Refill it with fresh clean water. If the nurse tank cart is at
hand, refill the nurse tank wash water as well.
The water needs to be changed daily. Water absorbs
ammonia vapor from the air, and becomes an
ammonium hydroxide solution over time.
When emptying wash tanks, use the time and water to
train operators on tank operations, and first aid rinsing
procedures.
Sealer Setup (NP3000A)
From the factory, sealers are preset for optimal shipping
configuration. The factory default settings are not likely to
be suitable for your field conditions.
Adjustments may also be required for different fields and
from season to season.
See “NH3 Sealer Adjustments” on page 80.
Model
Description
BOOM CAL
SPEED
CAL
METER
CAL
VALVE
CAL
1 (LH)
2 (CTR)
3 (RH)
NP3000-1230
w/o Section Control
30-Foot,
12-Row,
30 inch
360.0 in.
(914.4 cm)
598
a
a. Suggested initial value. Refine using calibration procedure in Raven SCS 450 manual.
Cable Tag
b
b. This value is printed on a durable tag attached to the meter cable.
Body Label
c
c. This value, for example “2123”, is printed on the label on the valve body.
NP3000-1230
w/ Section Control
30-Foot,
12-Row,
30 inch
120 in.
(304.8 cm)
120 in.
(304.8 cm)
1820 in.
(304.8 cm)
598
a
Cable Tag
b
Body Label
c
d
w/o Section Control
d. Side Dress. These figures presume passes with no overlap. For overlapped application, use the non-SD values at top.
32.5-Foot,
13-Row,
30 inch
390.0 in.
(990.6 cm)
598
a
Cable Tag
b
Body Label
c
w/ Section Control
NH
3
42.5-Foot,
17-Row, 30 inch
150 in.
(381.0 cm)
120 in.
(304.8 cm)
120 in.
(304.8 cm)
598
a
Cable Tag
b
Body Label
c
Figure 20
First Aid Water Station
