Plumbing Diagrams
Convention Liquid Diagrams begin on page 151.
NH
3
Plumbing Diagrams
See page 22 for a narrative.
NH
3
System Elements
The dual-cooler systems (page 149 and 150) differ from
the single-cooler systems (page 147 and 148) as follows:
• The inflow from the tank is split after the strainer
,
feeding two coolers
.
• Cooler outlets are merged prior to flow meter
.
• Refrigerant tap
is split.
• Two more tines
are dual-tube for vapor dispersal.
The section-control systems (pages 148 and 150) differ
from the single-section systems as follows:
• There is a check valve, bleed valve and 3-way flow
divider prior to section flow dividers.
• Each section flow divider has a shut-off solenoid valve.
A11. Acme cap
A31. Master Shut-Off Valve
A12. Acme inlet
A32. Refrigerant Tap
A13. Coupler Inlet Bleed Valve
A33. Refrigerant Line
A14. Breakaway Coupler
A34. Cooler Refrigerant Inlet
A15. Breakaway Hydrostatic Relief Valve
A35. Section Control Check Valve
A16. Coupler Outlet Bleed Valve
A36. Section Control Bleed Valve
A17. Supply Hose
A37. Section Control Relief Valve
A18. Emergency Shut-off Valve
A38. Section Flow Divider
A19. Strainer
A39. Section Shut-Off Valves
A20. Strainer Magnets
A40. Row Flow Divider(s)
A21. AccuFlow™ Super Cooler (Heat Exchanger)
A41. Flow Divider Manifold Inlet
A22. Cooler Intake
A42. Flow Divider Pressure Gauge
A23. Cooler Hydrostatic Relief Valve
A43. Flow Divider Outlet
A24. Cooler Outlet
A44. Flow Divider Plug
A25. Flow Meter
A45. Delivery Tube
A26. Drain Cap
A46. Coulter Tine (Single)
A27. Temperature Gauge
A47. Cooler Vapor Outlets (2)
A28. Pressure Gauge
A48. Vapor Tube
A29. Cooler Bleed Valve
A49. Coulter Tine (Dual)
A30. Control Valve
Legend:
For more details on components A11 through A49, see
“NH3 System Narrative” on page 22.
Liquid NH
3
Liquid Flow
NH
3
Vapor
Vapor Flow
Direction of Flow
Exception Flow
A19
A24
A25
A32
A49
