Great Plains 1525P Operator Manual - Manual (Page 37)

8/14/2006 118-949M
35 Adjustments
Shutting Off Seed Flow
Refer to Figure 34
This figure shows a sliding seed tube in the open
position. To shut off seed flow, move rear tubes
(shown) forward and front tubes backward. The
following instructions explain how to shut off seed
flow to each meter.
Refer to Figure 35
1. Remove the retaining clip and pull pin. Do not
remove cotter pin.
2. Move meter cap to position seed tube over
shut off pad.
Refer to Figure 36
3. Place pin in hole of meter cap and install re-
taining clip.
4. Repeat steps 1 through 3 for each meter.
NOTE: When pin with retaining clip is located
in the slot, sliding seed tube is open. When pin
with retaining clip is located in the hole, slid-
ing seed tube is closed.
Figure 34
Sliding Seed Tubes in open positions 22853
Shut off
Sliding seed
tube
Figure 35
22854
Retaining
clip
Sliding seed
tube
Figure 1 18303 Figure 36
22855
