Great Plains Manufacturing, Inc.
Appendix
35
2012-12-11
133-322M
136
803-169C
12
12
12
12
12
12
NUT HEX FLG. LOCK 1/2-13 PLT.
137
803-209C
0
0
0
63
78
48
NUT FLANGE LOCK 3/8-16 PLT
138
804-006C
2
2
2
2
2
2
WASHER LOCK SPRING 1/4 PLT
139
804-009C
14
14
14
2
2
2
WASHER LOCK SPRING 5/16 PLT
140
804-013C
12
12
12
12
12
12
WASHER LOCK SPRING 3/8 PLT
141
804-015C
27
27
27
13
13
13
WASHER LOCK SPRING 1/2 PLT
142
804-061C
6
6
6
0
0
0
WASHER MACH 1.50 X 1.00 X 18GA
143
804-113C
16
16
16
6
6
6
WASHER FLAT 1/2 USS HARD PLT
144
805-180C
6
6
6
0
0
0
PIN ROLL 1/4 X 1 1/2 LG PLT
145
806-060C
2
2
2
0
0
0
U-BOLT 1/2-13 X 6 1/32 X 7 1/4
146
808-194C
3
3
3
3
3
3
SPKT 40B22 7/8 HEX BORE & SS
147
808-256C
3
3
3
0
0
0
SPKT 40C23 X 7/8 HEX BORE
148
816-358C
63
78
48
63
78
48
SGS HOSE 122 RIBS
149
817-025C
3
3
3
0
0
0
NO. 40 12T IDLER SPKT.
150
817-806C
63
78
48
63
78
48
SMALL SEEDS CUP WIND SHIELD
151
818-055C
1
1
1
1
1
1
DECAL SLOW MOVING-GALV. BACKED
152
822-032C
12
12
12
0
0
0
FLANGETTE 52 MST
153
822-119C
6
6
6
0
0
0
BRG 7/8HEXX2.05OD SPH
154
a
838-160C
40
40
40
40
40
40
DECAL 3 COLOR STRIPE 2.50 WIDE
155
a
838-161C
1
1
1
1
1
1
DECAL LOGO&GP F/STRIPE 4 X 24
156
a
838-206C
1
1
1
1
1
1
DECAL 3S-4000
157
a
838-467C
1
1
1
1
1
1
DECAL SMALL SEEDS DANGER
a. These parts are pre-installed and are not called out in the instructions.
Callout
Part
Number
Quantity in Kit 133-
Part Description
-300A -301A -302A -319A -320A -321A
