Great Plains Manufacturing, Inc. Table of Contents Index Appendix 33
2012-12-11 Table of Contents Index 133-322M
Abbreviations
Part Lists
Existing Parts Affected
3S Three Section MNT Mount
ASY Assembly MST Metric Spherical Two-hole
BRG Bearing PLT Plated
CT Cutting RH Right Hand
CTR Center RHSNB Round Head Square Neck Bolt
DR Drive RL Roller
EWNT End Wheel No Till SAE Society of Automotive Engineers (standards)
FERT Fertilizer SDS Seeds
FLG Flanged SLT Slotted
GALV Galvanized SML Small
GP Great Plains SMV Slow Moving Vehicle
GR5 Grade 5 SPH Spherical
HEX Hexagonal (6-sided) SPKT Sprocket
HFS Hex Flange Screw SPTHD Special Thread
HHCS Hex Head Cap Screw (Bolt) SS Set Screw
ID Inside Diameter TB Tube
IN Inch THD Thread
JS Jackshaft THD CT Thread Cutting (self-tapping)
LG Long USS United States Standard (heavy duty standard)
LH Left Hand W/ with
MACH Machine X by
Callout
Part
Number
Description Disposition
11 119-190D HANDLE Removed and re-installed.
12 195-273S 40’-3S FERT DR SUBASSY LH Bolts and sprocket removed, and reinstalled.
13 150-138D 12’ EWNT LIGHT BRACKET Removed and re-installed.
14 248-251D MANUAL PAK MOUNTING PLATE Removed and re-installed.
15 802-034C HHCS 1/2-13X1 1/4 GR5 Removed and re-installed.
16 802-203C HFSS 1/2-13X1 1/2 GR5 Removed and re-installed.
17 803-169C NUT HEX FLG. LOCK 1/2-13 PLT. Removed and re-installed.
18 803-020C NUT HEX 1/2-13 PLT Removed and re-installed.
19 804-015C WASHER LOCK SPRING 1/2 PLT Removed and re-installed.
20 804-016C WASHER FLAT 1/2 SAE PLT Removed and re-installed.
21 805-180C PIN ROLL 1/4 X 1 1/2 LG PLT Removed and re-installed.
22 808-143C SPKT 40B12 7/8 HEX BORE W/SS Removed and re-installed.
