34
3S-4000/F/HD/HDF SGS
Great Plains Manufacturing, Inc.
133-322M
2012-12-11
New Parts
Kits:
133-300A 3S-4000 7.5" SMALL SEEDS BUNDL
133-301A 3S-4000 6" SMALL SEEDS BUNDL
133-302A 3S-4000 10" SMALL SEEDS BUNDL
133-319A 3S-4000F 7.5" SMALL SEEDS BNDL
133-320A 3S-4000F 6" SMALL SEEDS BNDL
133-321A 3S-4000F 10" SMALL SEEDS BNDL
Callout
Part
Number
Quantity in Kit 133-
Part Description
-300A -301A -302A -319A -320A -321A
101
133-322M
1
1
1
1
1
1
MANUAL 3S4000 SMALL SEEDS
102
123-491D
3
3
3
3
3
3
HANDLE MOUNT LH CHAIN GUARD
103
123-492D
3
3
3
3
3
3
HANDLE MOUNT RH CHAIN GUARD
104
123-939H
63
78
48
0
0
0
SMALL SEEDS TUBE WELDMENT
105
133-070D
1
1
1
1
1
1
3000 SMV MOUNTING BLADE
106
133-128H
0
0
0
63
78
48
SGS SIDE DELIVERY TUBE
107
133-153K
0
3
0
0
3
0
2600 SML SDS RH BOX ASY 6 IN
108
133-155K
3
0
0
3
0
0
2600 SML SDS RH BOX ASY 7.5 IN
109
133-157K
0
0
3
0
0
3
2600 SML SDS RH BOX ASY 10 IN
110
133-158H
3
3
3
3
3
3
SML SDS LH MOUNT WLDM
111
133-163K
3
3
3
3
3
3
2600 SMLSDS RH MOUNT&DRIVE ASY
112
133-324K
3
3
3
3
3
3
SML SDS ON FERT JS MNT ASY
113
136-064D
3
3
3
0
0
0
CHAIN RL #40 51 PITCHES
114
136-078D
3
3
3
3
3
3
CHAIN RL #40 52 PITCHES
115
136-104D
3
3
3
3
3
3
CHAIN RL #40 62 PITCHES
116
136-154D
3
3
3
3
3
3
CHAIN RL #40 214 PITCHES
117
195-269H
3
3
3
0
0
0
40’-3S FERT DRIVE WELDMENT RH
118
195-270D
1
1
1
0
0
0
HEX SHAFT 7/8,4000 FERT JS CTR
119
195-271D
1
1
1
0
0
0
HEX SHAFT 7/8,4000 FERT JS RH
120
195-272D
1
1
1
0
0
0
HEX SHAFT 7/8,4000 FERT JS LH
121
800-321C
126
156
96
126
156
96
HOSE CLAMP NO.12 3/4 ID
122
801-002C
126
156
96
0
0
0
SCREW HEX SLT10-16X1/2P.THD CT
123
802-004C
2
2
2
2
2
2
HHCS 1/4-20X3/4 GR5
124
802-007C
2
2
2
2
2
2
HHCS 5/16-18X3/4 GR5
125
802-034C
20
20
20
13
13
13
HHCS 1/2-13X1 1/4 GR5
126
802-041C
3
3
3
0
0
0
HHCS 1/2-13X3 1/2 GR5
127
802-203C
12
12
12
12
12
12
HFSS 1/2-13X1 1/2 GR5
128
802-282C
12
12
12
0
0
0
RHSNB 5/16-18X1 GR5
129
802-388C
12
12
12
12
12
12
HFS 3/8-16X1 GR5
130
802-427C
0
0
0
63
78
48
HFS 3/8-16X3 3/4 SPTHD
131
803-006C
2
2
2
2
2
2
NUT HEX 1/4-20 PLT
132
803-008C
14
14
14
2
2
2
NUT HEX 5/16-18 PLT
133
803-014C
12
12
12
12
12
12
NUT HEX 3/8-16 PLT
134
803-020C
24
24
24
13
13
13
NUT HEX 1/2-13 PLT
135
803-036C
6
6
6
0
0
0
NUT HEX JAM 1/2-13 PLT
