Great Plains Manufacturing, Inc. Table of Contents Index Adjustments 63
02/23/2011 Table of Contents Index 401-755M
Seed Firmer Adjustments
Series 25 row units include a standard seed flap, and
accept one of two optional seed firmers (which may be
included in your selected opener bundle).
Row unit disk blades may be sharp. Use caution when making
adjustments in this area. To adjust the Keeton
® seed firmer,
lower the planter until the disks of the row units are resting on
the ground.
Keeton ® Seed Firmer a Adjustment
The optional Keeton ® seed firmer is an engineered
polymer shape that slides down the seed trench. It traps
seeds as they exit the seed tube and firms them into the
bottom of the “V”.
Refer to Figure 70
The firmer is provided with a preset tension which is
recommended for using the first year. The tension
screw
can be tightened in subsequent years
according to your needs. Firmers should provide just
enough tension to push seeds to the bottom of the
trench.
Seed-Lok ® Seed Firmer Lock-Up
Optional Seed-Lok ® firming wheels provide additional
seed-to-soil contact. The wheels are spring loaded and
do not require adjusting. In some wet and sticky
conditions the wheels may accumulate soil. To avoid
problems associated with this, you can lock-up the
firmers.
Refer to Figure 71
To lock up a Seed-Lok
® wheel:
1. Raise planter. Insert lift assist cylinder locks.
2. Push up on Seed-Lok ® wheel until wheel arm
latches up.
To release a Seed-Lok ® wheel:
1. Lift up at Seed-Lok ® wheel to reduce force
required to release lever.
2. Flip lever up slightly until Seed-Lok ® wheel
releases.
a. Keeton ® is a registered trademark of Precision Planting, Inc.
Figure 70
Keeton ® Seed Firmer
28316
1
1
Figure 71
Seed-Lok ® Lock-Up
29985
3
2
2
2
3
