Page 114
110
YP625TD and YP925TD
Great Plains Manufacturing, Inc.
401-755M
02/23/2011
Chain Routing
See also “Chain Maintenance” on page 86.
Ground Drive Arm Chain
Legend:
Sprocket or idler Tooth count
Chain Pitch count
Direction of chain in motion
34T
56P
29885
U
D
F
B
L
R
20T
166P
23T
21T
